450w High Output Charging System - 107mm
    Purchase 450w High Output Charging System - 107mm
    • Part # 1231109
      450w High Output Charging System - 107mm

    • $539.00

    • Not in stock, we have more coming soon!

      Place an order to reserve.
      Caution! Our 450w High Output Charging System - 107mm does not fit all bike models. Please select your bike if you are not sure.
      Warning! Important information below in the description.



    -
    Write a Review
    Description Instructions Reviews Bike Fitment

    Description


    450w High Output Charging System (both 105mm and 107mm stator frame BMW models)

    Updated Design with fewer Components - One Kit fits ALL Airheads - no need to know the stator size

    The Kit includes all the components to replace your under-performing 240w BOSCH charging system. Featuring a Permanent Magnet Rotor which eliminates the brushes and potential rotor failure. The Hi-Output Stator produces significant AC voltage at lower RPM's not possible with the original system. The combined Voltage Regulator / Rectifier eliminates the two components most vulnerable to failure on the BOSCH charging system, namely the diode board and the voltage regulator. In addition the kit includes a Rotor Removal Tool, a new timing cover Oil Seal and a Caliper for accurate measurements. The new plug and play harness connects the new alternator to your Airhead electrical system efficiently and eliminates potential wiring errors and having to solder or crimp connectors.

    The Total Maximum Rating of the system is 32 Amps or 450 Watts with a smooth measured increase in power:

    • 29 Amps / 400 Watts @ 5000 RPM
    • 25 Amps / 350 Watts @ 3000 RPM
    • 20 Amps / 280 Watts @ 2000 RPM

    With correct installation reliability and confidence can be restored to your BMW's charging system - see Installation Instructions on the preparation of your vehicle and installation of the EnDuraLast Charging System in a step-by-step easy to understand manner. The high amperage output of this system at low engine RPM's allows use of additional lighting, heating and other accessories.

    Install this Charging System upgrade NOW for the FINAL improvement to your Charging System!

    • Bolts right on and wires up simply
    • Original Equipment, New, Modern charging technology
    • Brushless design eliminates worn out rotor slip rings and brushes
    • High-tech permanent magnet rotor will never overheat and short out
    • The critically important higher amperage output of this system at low engine RPM's
    • Updates the BMW R Airhead original, under-performing 20 amp (max) alternator and rectifier
    • Allows use of lighting, heating and other accessories to be used without discharging the battery or overloading the original charging system
    • Combination electronic voltage regulator /rectifier housed in finned cast-aluminum housing which mounts remotely for increased cooling and reliability
    • Original alternator/engine cover fits over the alternator with no alterations required
    • Eliminates "burnt out warning light" no-charge condition of Bosch systems
    • Designed and manufactured to modern OEM specifications



    NOTE:

    • Not recommended for use with lithium iron batteries. A small percentage of customers report failure of the voltage regulator/rectifier when using dry cell batteries due to the greater internal resistance which can cause components to overheat. We recommend conventional wet acid or sealed AGM batteries.
    • Can also be used with BMW 1970-1976 w/105mm stator frames


    NOTE: The /5 Airhead models require a starter relay modification. Please review the Instructions PDF for details.

    Instructions




    Customers Who Bought This Product Also Bought


    Reviews
    Write a review

    There are no reviews for this item yet.

    Write Review:
    450w High Output Charging System - 107mm
    • Click/Tap a star to rate. 5 stars is the best.
    • All fields are required except "where you're from".
    • Your email is for verification purposes only and will NOT be published or shared. See our Privacy Policy.

    Thank you for your review!

    Enter only the red text:  3Ry1731771Arq!


    Essential Tools





    Bike Fitment


    R50-5

    1970 · 1971 · 1972 · 1973

    R60-5

    1970 · 1971 · 1972 · 1973

    R75-5

    1970 · 1971 · 1972 · 1973

    R60-6

    1974 · 1975 · 1976

    R75-6

    1974 · 1975 · 1976

    R90-6

    1974 · 1975 · 1976

    R90 S

    1974 · 1975 · 1976

    R60-7

    1976 · 1977

    R75-7

    1976 · 1977

    R100-7

    1976 · 1977 · 1978

    R100 RS

    1976 · 1977 · 1978 · 1979 · 1980 · 1981 · 1982 · 1983 · 1984 · 1988 · 1989 · 1990 · 1991 · 1992 · 1993

    R100 S

    1976 · 1977 · 1978 · 1979 · 1980

    R80

    1977 · 1978 · 1979 · 1980 · 1985 · 1986 · 1987

    R45

    1978 · 1979 · 1980 · 1981 · 1982 · 1983 · 1984 · 1985

    R65

    1978 · 1979 · 1980 · 1981 · 1982 · 1983 · 1984 · 1985 · 1986 · 1987

    R100-T

    1978 · 1979 · 1980 · 1981 · 1982 · 1983 · 1984

    R100 RT

    1978 · 1979 · 1980 · 1981 · 1982 · 1983 · 1984 · 1988 · 1989 · 1990 · 1991 · 1992 · 1993 · 1994 · 1995

    R80 G-S

    1980 · 1981 · 1982 · 1983 · 1984 · 1985 · 1986 · 1987

    R80 GS

    1987 · 1988 · 1989 · 1990 · 1991 · 1992 · 1993 · 1994 · 1995

    R100 CS

    1980 · 1981 · 1982 · 1983 · 1984

    R65 LS

    1981 · 1982 · 1983 · 1984

    R80 RT

    1982 · 1983 · 1984 · 1985 · 1986 · 1987

    R80 ST

    1982 · 1983 · 1984

    R65 GS

    1987 · 1988 · 1989 · 1990 · 1991 · 1992

    R100 GS

    1987 · 1988 · 1989 · 1990 · 1991 · 1992 · 1993 · 1994 · 1995

    R100 GSPD

    1989 · 1990 · 1991 · 1992 · 1993 · 1994 · 1995

    R100 R

    1991 · 1992 · 1993 · 1994 · 1995

    R100 R Mystik

    1994 · 1995
