Description
Kellermann Blink Relay
The load independent R 2 flasher relay is the universal problem solver when using LED and halogen turn indicators. It replaces all original 2-3 pole flasher relays and delivers a constant and correct flashing frequency. Connection is simple. If following the conversion to LED turn indicators, the non-activated indicators also flash, then all that is required is for the relay to be connected to a left and a right indicator in order to reliably cure this problem .
- Suitable for flasher switches
- Replaces the original 2-3 pole flasher relay
- Suitable for Motorcycles with 12 volt electrical systems
- Restricts the accompanying flashing of non-activated indicators
- Small dimensions 30 x 30 x 10 [mm] (L/W/H)
- Switching capacity 0,5 - 85 watt
- Load independent
- ECE-tested
- Made in Germany
Connection of the indicator:
- Black cable: Ground (31 or E)
- Red Cable: Continuous (49 or B)
- Orange / Red cable: Clocked plus (49a or L)
* All necessary components required for installation are included
InstructionsCustom Build Parts
This part does not have OEM fitment and is meant for Custom Applications - Fitment is not model specific.
