Joost Elektronikbox Version B

    Sign up to be notified when this product is back in stock!
    Purchase Joost Elektronikbox Version B
    • Part # 361992
      Joost Elektronikbox Version B

    • No reviews yet.
    • $349.95

    • In Stock
      Caution! Our Joost Elektronikbox Version B does not fit all bike models. Please select your bike if you are not sure.


      Write a Review

    Description Instructions Reviews Accessories Bike Fitment

    Description


    Joost Elektronikbox Version B

    Electronic box version B was developed by various inquiries of customers, who wanted a box for a fast installation, with which a somewhat larger construction plays no role compared to the other boxes. The B-Box can be powered via the normal ignition switch, or an optional RFID antenna can be connected for key-less access. Alternatively, you can also connect an optional Bluetooth module, which allows complete control of your bike via your mobile phone. It has 8 status LEDs in the box to allow for quick diagnosis during installation and when setting the various functions. It also has an integrated 20 Amp inline fuse for added protection. The outputs are short-circuit proof and self-resetting.

    Dimensions (LxWxH): 92 mm x 50 mm x 36 mm (including terminal plug)
    Maximum ambient temperature: 80 degrees Celsius
    Maximum current from 12V connection: 20 amps.

    The box controls the following functions:
    • Ignition (with or without side stand switch)
    • Starter (with or without neutral switch switch)
    • Main beam and low beam with switches or buttons
    • Indicators via switches or buttons
    • Brake light with or without dimming function
    • Horn
    Maximum continuous output current:
    • 5 Ampere for high/low beam
    • 3 Ampere for other outputs
    Other Specifics
    • Power consumption in standby mode: Ca. 0.2 mA
    • Housing: Black impact resistant ABS plastic, waterproof potted
    • Input voltage: 18 Volt
    • Connections: 2.5 qmm

    Instructions



    Reviews


    Be the First to Review


    Related & Recommended
    Products




    Essential Tools





    Bike Fitment


    R50-5

    1970 · 1971 · 1972 · 1973

    R60-5

    1970 · 1971 · 1972 · 1973

    R75-5

    1970 · 1971 · 1972 · 1973

    R60-6

    1974 · 1975 · 1976

    R75-6

    1974 · 1975 · 1976

    R90-6

    1974 · 1975 · 1976

    R90 S

    1974 · 1975 · 1976

    R60-7

    1976 · 1977

    R75-7

    1976 · 1977

    R100-7

    1976 · 1977 · 1978

    R100 RS

    1976 · 1977 · 1978 · 1979 · 1980 · 1981 · 1982 · 1983 · 1984 · 1988 · 1989 · 1990 · 1991 · 1992 · 1993

    R100 S

    1976 · 1977 · 1978 · 1979 · 1980

    R80

    1977 · 1978 · 1979 · 1980 · 1985 · 1986 · 1987

    R45

    1978 · 1979 · 1980 · 1981 · 1982 · 1983 · 1984 · 1985

    R65

    1978 · 1979 · 1980 · 1981 · 1982 · 1983 · 1984 · 1985 · 1986 · 1987

    R100-T

    1978 · 1979 · 1980 · 1981 · 1982 · 1983 · 1984

    R100 RT

    1978 · 1979 · 1980 · 1981 · 1982 · 1983 · 1984 · 1988 · 1989 · 1990 · 1991 · 1992 · 1993 · 1994 · 1995

    R80 G-S

    1980 · 1981 · 1982 · 1983 · 1984 · 1985 · 1986 · 1987

    R80 GS

    1987 · 1988 · 1989 · 1990 · 1991 · 1992 · 1993 · 1994 · 1995

    R100 CS

    1980 · 1981 · 1982 · 1983 · 1984

    R65 LS

    1981 · 1982 · 1983 · 1984

    R80 RT

    1982 · 1983 · 1984 · 1985 · 1986 · 1987

    R80 ST

    1982 · 1983 · 1984

    R65 GS

    1987 · 1988 · 1989 · 1990 · 1991 · 1992

    R100 GS

    1987 · 1988 · 1989 · 1990 · 1991 · 1992 · 1993 · 1994 · 1995

    R100 GSPD

    1989 · 1990 · 1991 · 1992 · 1993 · 1994 · 1995

    R100 R

    1991 · 1992 · 1993 · 1994 · 1995

    R100 R Mystik

    1994 · 1995
