Description
MS-01 Multifunction Speedometer
The MS-01 multifunction meter is the newest addition for enthusiasts who enjoy multiple readings from their ride. It features a modern negative LCD screen to display all of your information. Compact, lightweight and easy to operate, this modern meter offers a clean and simple design. This universal gauge can be used for any application.
Specifications
(R= Range U=Unit)
(R= Range U=Unit)
- Speedometer
- R: 0 ~ 124 MPH (0 ~ 199 km/h)
- U: 1 MPH or km/h (alternative)
- Odometer
- R: 0 ~ 99,999 miles (km)
- U: 1 mile (km)
- Tripmeter A/B
- R: 0 ~ 9,999.9 miles (km)
- U: 0.1 mile (km)
- Speeding warning light
- R: 19 ~ 124 MPH (30 ~ 199 km/h)
- U: 1 MPH(km/h)
- warning light on when ≥ setting value
- Tire circumference
- R: 300 ~ 2,500 mm
- U: 1 mm
- Sensitive point: 1 ~ 40
- Gear indicator (learning)
- R: OFF, N, 1 ~6, the highest gear
- Oil maintenance
- R: 300 ~ 10,000 miles (500 ~ 16,000km), OFF
- U: 100 miles (km)
- Bar segment tachometer
- R: 0 ~ 10,000 RPM /0 ~ 13,000 RPM
- U: 0 ~ 10,000 RPM (250 RPM/segment)
- 0 ~ 13,000 RPM (250 RPM/segment)
- RPM input pulse
- R: POS(+) / NEG(-)
- RPM signal
- R: P-0.5 / P-1 / P-1.5 / P-2 / P-2.5 /
- P-3 / P-4 / P-5 / P-6 / P-9 / P-10 /
- P-11 / P-12 / P-17 / P-18 / P-23 / P-24 /
- P-34 / P-36
- First-stage warning for over-RPM (Illuminated)
- R: 0 ~ 10,000 RPM
- Setting: 3,000 ~ 9,750 RPM
- R: 0 ~ 13,000 RPM
- Setting: 3,000 ~ 12,750 RPM
- Signaling light on (green) for over-RPM when ≥ set value
- Second-stage warning for over-RPM (Illuminated)
- R: 0 ~ 10,000 RPM
- Setting: 3,000 ~ 9,750 RPM
- R: 0 ~ 13,000 RPM
- Setting: 3,000 ~ 12,750 RPM
- Signaling light on (red) for over-RPM when ≥ set value
- Third-stage warning for over-RPM (Blinking)
- R: 0 ~ 10,000 RPM
- Setting: 3,250 ~ 10,000 RPM
- R: 0 ~ 13,000 RPM
- Setting: 3,250 ~ 13,000 RPM
- Signaling light blinking (green/red) for over-RPM when ≥ set value
- U: 100 RPM
- Temperature & Max. temp record
- R:
- 1- OFF
- 2- Cylinder head temperature
- P-1 -20 ~ 200˚C (-4 ~ 392°F)
- P-2 -40 ~ 185˚C (-40 ~ 365°F)
- P-3 -20 ~ 220˚C (-4 ~ 428°F)
- P-4 -20 ~ 200˚C (-4 ~ 392°F)
- P-5 -20 ~ 120˚C (-4 ~ 248°F)
- P-6 -30 ~ 200˚C (-22 ~ 392°F)
- P-1A -20 ~ 200˚C (-4 ~ 392°F)
- P-2A -40 ~ 185˚C (-40 ~ 365°F)
- P-5A -20 ~ 120˚C (-4 ~ 248°F)
- P-6A -30 ~ 200˚C (-22 ~ 392°F)
- 3- Temperature sensor
- P-250 0 ~ 250˚C (32 ~ 482°F)
- Thermometer
- R: 32.0 ~ 482.0 ˚F (0 ~ 250 ˚C)
- U: 0.1 °C (°F)
- Over Temperature warning
- R: 122 ~ 356°F (50 ~ 180°C)
- U: 3°F (5°C)
- Temp warning on when > value
- Fuel meter
- R: 6 levels
- U: 1 level = 16.6 %
- Fuel resistance
- R: OFF, 100 Ω, 250 Ω, 270 Ω, 390 Ω , 510 Ω, 1200 Ω, SW
- Low fuel warning
- R: 0 ~ 3 segment
- U: 1 segment, low fuel warning will be blinking ≥ value
- Clock
- R: 1:00 ~ 12:59 (12H)
- Voltmeter
- R: DC 8.0 ~ 18.0 V
- U: DC 0.1 V
- Low voltage warning
- R: DC 8.0 ~ 13.0 V
- U: 0.1
- Signaling light on ≥ value
- Backlight brightness
- R: 1/5(Darkest) ~ 5/5(Brightest)
- U: 1/5
- ABS
- R: ON / OFF
- AFR
- R: ON / OFF
- R: 12.1 ~ 17.5
- U: 0.1
- Indicator lights
- Neutral / High beam / Turn signals /
- Check engine / ABS / Warning
- Effective temperature range
- 14 ~ 140 °F (‑10 ~ 60 °C)
- Effective voltage
- DC 12 V
InstructionsCustom Build Parts
This part does not have OEM fitment and is meant for Custom Applications - Fitment is not model specific.
