VAPE /5, /6 105mm Complete System
    Purchase VAPE /5, /6 105mm Complete System
    • Part # 706799900
      VAPE /5, /6 105mm Complete System

    • $749.95

    • In Stock
      Caution! Our VAPE /5, /6 105mm Complete System does not fit all bike models. Please select your bike if you are not sure.



    -
    Write a Review
    Description Instructions Reviews Accessories Bike Fitment

    Description


    VAPE /5, /6 105mm Complete System


    The VAPE (pronounced VaahPeh) is a top quality, European product that will “modernize” the electrical systems on your classic BMW, providing improved reliability, performance as well as passive and active safety. This set will replace the entire charging and ignition system with reliable, modern components.

    This set consists of a complete system including Rotor, Stator, Coil-CDI, Regulator, and other hardware. Replaces the stock 12V alternator (including diode plate and regulator) as well as all ignition parts (points or hall element). There is no need for changes to the engine casing. This D/C system will run head lights, tail lights, turn signals and charge the battery. It is a magnet based alternator with integrated solid state ignition; output at 12V/190W DC. The alternator is brushless and there are no parts to wear out, making this system maintenance free.

    Included
    • Pre-assembled Stator Rotor
    • Flywheel (rotor)
    • Electronic Advance Unit
    • Regulator/Rectified
    • Twin Ignition Coils
    • Relay with cables
    • Rotor bolts M8 with washer
    • Three M5 screws
    • Installation cables/hardware

    The VAPE ignition system is a magneto based generator with integrated, fully electronic ignition. It is equipped with a tiny AC regulator to run lighting equipment, thus eliminating the need to run a battery. VAPE external flywheel type ignitions are an analog type, CDI ignition with 80-100 watts of 12-volt lighting capacity capable of delivering up to 40,000 volts.


    Advantages
    • Does not require changes on crankcase or any other permanent modifications
    • Timing may now be fine tuned without taking the rotor off by turning body in long holes
    • Solid state ignition and advance
    • Reliable ignition with solid spark
    • Improved starting performance, better fuel burning
    • Eliminates points, condenser, centrifugal advance and upgrades the charging system
    • The system is technically capable of running without battery

    Important note:
    1. VAPE instructions - "not for BMW models with lightened flywheel" such as e.g. aluminum flywheels. VAPE systems are exclusively destined to replace stock ignition systems in classic and vintage motorcycles whose engine characteristics have not been modified aftermarket.
    2. Larger cc BMW with older e-starter might have starting problems with this systems. The starter does not reach the needed starting revs for the engine to start. For this reason the R90S and R100 models are excluded from fitment.


    Additional Information:
    • For /6 models manufactured prior to 09/751
    • Does not support existing electronic revolution counter, rev-meter/tachometer
    • Only 190 watts, which is more than adequate but less electric power than the stock alternator
    • Please do not use any spark amplifying cables, this will disturb the system and possibly damage it
    • Do not use spark plugs with an internal suppression resistor (e.g. spark plugs coded with an "R" for resistor)

    1The diameter of the original alternator stator was changed from 105mm to 107mm in 09/75. If you are unsure which version you have, we suggest removing the alternator stator and carefully measuring the diameter across the part of the stator that makes contact with and is fitted to the timing cover.

    Instructions



    Reviews
    Write a review

    There are no reviews for this item yet.

    Write Review:
    VAPE /5, /6 105mm Complete System
    • Click/Tap a star to rate. 5 stars is the best.
    • All fields are required except "where you're from".
    • Your email is for verification purposes only and will NOT be published or shared. See our Privacy Policy.

    Thank you for your review!

    Enter only the red text:  3Ry83859Arq!


    Related & Recommended
    Products




    Essential Tools





    Bike Fitment


    R50-5

    1970 · 1971 · 1972 · 1973

    R60-5

    1970 · 1971 · 1972 · 1973

    R75-5

    1970 · 1971 · 1972 · 1973

    R60-6

    1974 · 1975

    R75-6

    1974 · 1975

    R90-6

    1974 · 1975
